Introduction
In this tutorial, we'll show you how to use Smart Materials for matless cutting on the Vinyl Cutter. Matless cutting skips the cutting mat entirely — the material feeds through the machine directly from a roll holder, which is faster for long cuts and lets you work with materials that don't stick well to a mat.
This tutorial uses the AU-relevant workflow: a roll of Matless Glitter Heat Transfer Vinyl fed straight from the holder, cut, weeded, and then pressed onto a garment with a heat press. The full sequence runs from machine setup to a finished pressed design.
Quick overview of what we'll cover:
- Set up the machine and load the material
- Create your design
- Set up the cutting parameters
- Start cutting
- Weed and heat press your design
Step 1: Set Up the Machine & Load the Material
First, press the Power button to turn on the machine. Attach the roll holder to the front of the machine.
Then place the roll onto the holder.
Pull out enough vinyl and align both edges with the cutting mat slot. Make sure the material is straight and properly positioned.
Then, press the Load button to feed the material into the machine.
Step 2: Create Your Design
Open HTVRONT IdeaStudio and connect your C2 Cutting Machine. Click the "+" button to start a new project.
On the right side of the canvas, select "Matless Materials" then set your material size accordingly.
You can then upload your own design or choose one from the "Library". Adjust the size and position of your design as needed.
You can also click "Layers" on the right side of the screen, and select the colour you want to cut.
Once you've made your selection, click "Make".
Step 3: Set Up the Cutting Parameters
Next, select the colour group you'd like to cut. Under "Operation", the default option is "Cut".
Then, under "Materials", select "Matless Glitter Heat Transfer Vinyl". The recommended cutting settings will be applied automatically.
Since we're cutting heat transfer vinyl, remember to mirror your design before cutting.
📌 Matless vs mat-based cutting. The matless workflow here is specific to "smart" materials — the ones designed to feed through the machine without a mat backing. If your next project is cutting standard adhesive vinyl for stickers or decals, that usually goes on a cutting mat with the standard blade, not through the roll holder. The material type you pick in IdeaStudio tells the machine which path to take.
Once everything looks good, click "Add to Task".
Step 4: Start Cutting
Before cutting, make sure the material is loaded straight and there is enough space in front of and behind the machine. Then, click "Start" to begin cutting.
The machine will automatically feed the material and cut your design.
Once cutting is complete, use the built-in cutter on the holder to trim the material.
Then, remove the holder.
Press the "Load/Unload" button and take out the cut material.
Step 5: Weed and Heat Press Your Design
Now weed away the excess vinyl.
Next, place the design onto your project with the carrier sheet facing up.
Then heat press according to the recommended settings for your material.
Once the material has cooled as recommended, carefully peel away the carrier sheet. And your project is complete.
Video Tutorial
Watch the 2-minute 53-second walkthrough of the full matless cutting and pressing process below.
Conclusion
Matless cutting on the C2 is five steps: set up the roll holder, create the design in IdeaStudio with "Matless Materials" selected, choose the matching material preset, cut, then weed and press. The workflow skips the cutting mat entirely, which makes it faster for longer designs and lets you work with smart materials that don't stick to a mat.
From here, the natural next step is to apply the cut design to fabric with a heat press. If your next project switches to standard materials rather than smart ones, the mat-based lessons cover that path — and if the design changes from Heat Transfer Vinyl to adhesive vinyl, the cut settings change but the machine and the IdeaStudio workflow stay the same.
FAQ
These are the questions that come up most often when running matless cutting for the first time.
What are "Smart Materials" and why do they work without a mat?
Smart Materials are the specific materials designed to feed through the C2 without a cutting mat. They have a stiffer backing that holds its shape as it passes through the machine's rollers, so the blade can cut cleanly without the support a mat normally provides. Standard HTV and adhesive vinyl are not Smart Materials — those need a cutting mat.
Can I use regular HTV in matless mode?
No. Matless mode only works with materials the machine recognises as matless-capable — the material preset in IdeaStudio tells the machine which feed path to use. Standard HTV is too flexible and will wrinkle or slip inside the machine. For standard HTV, use the mat-based workflow from the earlier lessons.
How do I keep the material straight when loading it from the roll?
Pull out enough material so both edges align with the cutting mat slot before pressing Load. If the material goes in slightly off-angle, the cut lines will be skewed relative to the design. Check both edges before hitting Load, and adjust the roll holder if the material is drifting to one side.
What's the built-in cutter on the holder for?
It trims the material off the roll after cutting, without needing a separate pair of scissors. Once the design has been cut, slide the built-in cutter across the material to separate it from the roll. That keeps the roll end clean for the next project.
Why do I need to mirror the design if it's matless cutting?
Because this tutorial is still cutting Heat Transfer Vinyl, just in matless form. HTV is pressed face-down onto fabric, so the design needs to be mirrored so it reads correctly on the finished garment. The matless workflow doesn't change that — mirroring is a property of HTV, not of the feeding method.
Keep Learning
Matless cutting is one of six operations the C2 Vinyl Cutter supports. The rest of the series covers deep cutting, scoring, foil transfer, print-then-cut, and drawing — plus the heat presses you can pair with the machine for fabric projects.
