Introduction
In this lesson, we'll show you how to use the foil transfer function on the Vinyl Cutter to add metallic details to cardstock. Foil transfer presses a coloured foil sheet onto the material along a preset design, leaving a shiny, metallic finish that a blade alone can't produce.
The workflow is a single pass — no blade swap in the middle, unlike the scoring lesson. You install the foil transfer tip, load cardstock with foil on top, set the foil parameters in IdeaStudio, and run the machine once.
Quick overview of what we'll cover:
- Install the foil transfer tip
- Prepare and load the material
- Create your design
- Set the foil parameters
- Start foiling and reveal your design
Step 1: Install the Foil Transfer Tip
The foil transfer tool comes with three tip sizes: Bold, Medium, and Fine.
Choose the tip that works best for your design. Insert the selected tip into the foil transfer housing and make sure it is fully seated. Here we're choosing "Bold".
Then open the tool clamp.
Place the foil transfer housing inside.
And close the clamp securely.
📌 Tip size matters later. Whatever tip you install here — Bold, Medium, or Fine — you'll need to select the same size in IdeaStudio in Step 4. A mismatch between the physical tip and the software setting produces a weak or patchy transfer.
Step 2: Prepare and Load the Material
Next, place the cardstock onto a light-stickiness cutting mat and press it down firmly. Place the foil transfer sheet over the cardstock with the coloured side facing up. Smooth out the foil and secure the edges with masking tape.
Make sure the foil stays flat and the tape does not cover the area you want to foil.
Next, press the Power button to turn on the machine. Align the mat with the machine guides, then press the Load button to load it into the machine.
Step 3: Create Your Design
Open HTVRONT IdeaStudio and connect your C2 Cutting Machine.
On the canvas, "Upload" your own design.
Or choose one from the "Library".
Adjust the size and position of your design as needed, then click "Make" to enter the cutting settings page.
Step 4: Set the Foil Parameters
Next, select the colour group you'd like to foil transfer.
Under "Operation", you can choose "Cut", "Score", "Foil", or "Draw". Here, select "Foil".
And then select the "Size" of your foil tip. Since we previously selected the "Bold" foil tip, we need to choose the corresponding size here.
Since we're using foil sheet and cardstock paper, select "Foil sheet + Kraft Cardstock Paper".
The "Making Force" will automatically adjust based on the selected material.
Once everything is set, click "Add to Task" to open the "Task List".
Step 5: Start Foiling and Reveal Your Design
Click "Start" to begin.
The machine will automatically transfer the design onto the cardstock.
Keep the mat and material in place until the process is completely finished.
Once foiling is complete, unload the mat from the machine.
Carefully remove the masking tape and peel away the foil transfer sheet.
And your foil project is complete.
Video Tutorial
Watch the 2-minute 42-second walkthrough of the full foil transfer process below.
Conclusion
Foil transfer on the C2 is a single-pass operation: install the foil tip, load the cardstock with the foil sheet on top, set the foil parameters in IdeaStudio, then run the machine once and peel. The whole process takes about ten minutes from setup to finished piece.
From here, foil transfer pairs naturally with the scoring lesson — a card that's scored for folding and foiled for a metallic accent is a two-operation project on the same machine. And if a project changes material entirely, say cutting adhesive vinyl for a sticker or Heat Transfer Vinyl for a T-shirt, the workflow shifts to a pure cut and, for HTV, a heat press to apply it.
FAQ
These are the questions that come up most often when running foil transfer for the first time.
Which foil tip size should I start with?
Start with Bold. It produces the most visible metallic finish and is the most forgiving if the foil or material isn't perfectly flat. Medium and Fine are for detailed designs with thin lines — they give a crisper result but are less tolerant of small air bubbles under the foil.
Why does the software ask for the foil tip size?
Because the tip size changes the pressure and coverage the machine applies. The Bold tip covers a wider path, the Fine tip a narrower one. If you install Bold but select Fine in IdeaStudio (or the reverse), the transfer will come out either patchy or over-pressed. The software setting has to match the physical tip.
Can I reuse the foil sheet after one pass?
Sometimes. If the design only used a small portion of the foil sheet, the unused area can be reused for another project. But once the foil has been pressed, the transferred area is spent — it won't transfer a second time. Check the sheet after peeling: if there's still a clear, unmarked metallic area, it's reusable.
Why is my foil transfer patchy or incomplete?
Three common causes: the foil wasn't taped flat enough, so air pockets lifted it off the cardstock; the tip size in IdeaStudio didn't match the physical tip; or the cardstock surface wasn't clean. Smooth the foil fully, secure all four edges with tape, and double-check the tip size in the software before starting.
Can I foil transfer onto materials other than cardstock?
Foil transfer is designed for paper and cardstock — smooth, flat surfaces that accept the foil cleanly. It's not the right operation for adhesive vinyl or HTV, which are cut rather than foiled. For fabric projects, the foil sheet doesn't adhere the way it does to cardstock, so HTV and a heat press are the right combination instead.
